Diodes Incorporated PI49FCT3807BQE Clock Buffers 10 Output Non Inverting Clock

Width: 3.99 mm

Height: 1.5 mm

Length: 8.74 mm

Mounting Style: SMD/SMT

Number of Outputs: 10 Output

Quiescent Current: 30 uA

Supply Voltage - Max: 3.6 V

Supply Voltage - Min: 3 V

Pd - Power Dissipation: 500 mW (1/2 W)

Maximum Input Frequency: 20 MHz

Propagation Delay - Max: 3.8 ns

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C
