Diodes Incorporated PAM8301AAF 1-Channel Mono 1.5W MONO FILTERLESS CLASS-D AUDIO AMP

Class: Class-D

Shutdown: Shutdown

Unit Weight: 15 mg

Output Power: 1.5 W

Mounting Style: SMD/SMT

THD plus Noise: 0.3 %

Moisture Sensitive: Yes

Number of Channels: 1 Channel

Supply Voltage - Max: 5.5 V

Supply Voltage - Min: 2.5 V

Audio - Load Impedance: 8 Ohms

Operating Supply Current: 4 mA

Operating Supply Voltage: 3 V, 5 V

SNR - Signal to Noise Ratio: 78 dB

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C

PSRR - Power Supply Rejection Ratio: 45 dB
