Diodes Incorporated AP7312-1830FM-7 Linear Regulator Dual 150mA LDO Reg 60uA 1.8 to 3.0 65dB

Output Type: Fixed

Unit Weight: 24 mg

Mounting Style: SMD/SMT

Output Current: 150 mA

Output Voltage: 1.8 V, 3 V

Dropout Voltage: 150 mV

Line Regulation: 0.01 %/V

Load Regulation: 0.6 %

Number of Outputs: 2 Output

Quiescent Current: 60 uA

Input Voltage - Max: 6 V

Input Voltage - Min: 2 V

Dropout Voltage - Max: 200 mV

Pd - Power Dissipation: 2.2 W

Voltage Regulation Accuracy: 2 %

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C

PSRR / Ripple Rejection - Typ: 65 dB
