Wiring: 3-WIRE (Shield cable 3Cx24AWG)
Range: 300~5300mm
Dead band: 300mm
Accuracy: Full Scale ±0.25%
Resolution: 1mm
Temp. Comp.: Automatic in full scale
Beam width: 11˚
Current consumption: Max 100mA
Supply Voltage: DC 24V
Output Signal: CURRENT DC 4~20mA ( DC 20~4mA) (OPTION) RS485 (Modbus RTU)
Process Temp.: -20℃~60℃
Pressure: 0.7~2.0 Kgf/㎠
Mounting: 1.5 inch - 11.5 NPT
Material: Head - PBT-FR-GF10
(OPTION) Flange - PVC
(OPTION) Extention port - MC Nylon
Probe - PVDF kynar 720
