Delta Electronics, Inc. PE01D1205A Isolated DC/DC Converter, +/-5Vout, 1W

Width: 6.1 mm (0.24 in)

Height: 10.2 mm (0.402 in)

Length: 19.5 mm (0.768 in)

Industry: Medical, Industrial

Unit Weight: 2.500 g

Output Power: 1 W

Input Voltage: 10.8 V to 13.2 V

Mounting Style: Through Hole

Isolation Voltage: 1 kV

Number of Outputs: 2 Output

Input Voltage - Max: 13.2 V

Input Voltage - Min: 10.8 V

Input Voltage, Nominal: 12 V

Output Current-Channel 1: 100 mA

Output Current-Channel 2: 100 mA

Output Voltage-Channel 1: 5 V

Output Voltage-Channel 2: - 5 V

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C
