Delta Electronics, Inc. PD01D0512A Isolated DC/DC Converter, +/-12Vout, 1W

Width: 6.1 mm (0.24 in)

Height: 10.2 mm (0.402 in)

Length: 19.5 mm (0.768 in)

Unit Weight: 2.500 g

Output Power: 1 W

Input Voltage: 4.5 V to 5.5 V

Mounting Style: Through Hole

Number of Outputs: 2 Output

Input Voltage - Max: 5.5 V

Input Voltage - Min: 4.5 V

Input Voltage, Nominal: 5 V

Output Current-Channel 1: 42 mA

Output Current-Channel 2: 42 mA

Output Voltage-Channel 1: 12 V

Output Voltage-Channel 2: - 12 V

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C
