Delta Electronics, Inc. E35SE24006PDPG Isolated 9-60Vin 24V 6A 150W 1/8 brick

Width: 22.8 mm (0.898 in)

Height: 13.5 mm (0.531 in)

Length: 58.4 mm (2.299 in)

Industry: Industrial

Dimensions: 58.4 mm x 22.8 mm x 13.5 mm

Unit Weight: 50.500 g

Output Power: 150 W

Input Voltage: 9 V to 60 V

Mounting Style: Through Hole

Isolation Voltage: 4.242 kV

Number of Outputs: 1 Output

Input Voltage - Max: 60 V

Input Voltage - Min: 9 V

Input Voltage, Nominal: 35 V

Output Current-Channel 1: 6 A

Output Voltage-Channel 1: 24 V

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C
