Delta Electronics, Inc. DRF-48V120W1GTA Switching Supplies 120W 48V 2.5A Spring Clamp Terminal

Width: 30 mm (1.181 in)

Height: 123.6 mm (4.866 in)

Length: 116.8 mm (4.598 in)

Industry: Industrial

Input Type: 1-Phase / Single Phase

Unit Weight: 499 g

Output Power: 120 W

Input Voltage: 100 VAC to 240 VAC, 127 VDC to 375 VDC

Mounting Style: DIN Rail Mount

Isolation Voltage: 4 kVAC

Number of Outputs: 1 Output

Open Frame/Enclosed: Enclosed

Output Current-Channel 1: 2.5 A

Output Voltage-Channel 1: 48 VDC

Maximum Operating Temperature: + 70 C

Minimum Operating Temperature: - 40 C
