Delta Electronics, Inc. DB02D1215A Isolated DC/DC Converter, +/-15Vout, 2W

Width: 13.7 mm (0.539 in)

Height: 8 mm (0.315 in)

Length: 23.8 mm (0.937 in)

Industry: Medical, Industrial

Unit Weight: 5.100 g

Output Power: 2 W

Input Voltage: 9 V to 18 V

Mounting Style: Through Hole

Isolation Voltage: 1.5 kV

Number of Outputs: 2 Output

Input Voltage - Max: 18 V

Input Voltage - Min: 9 V

Input Voltage, Nominal: 12 V

Output Current-Channel 1: 67 mA

Output Current-Channel 2: 67 mA

Output Voltage-Channel 1: 15 V

Output Voltage-Channel 2: - 15 V

Maximum Operating Temperature: + 80 C

Minimum Operating Temperature: - 40 C
