Delta Electronics, Inc. AS228P-A CPU AS200 CPU, PNP Sourcing output, Embedded Ethernet , 2x RS-485, USB port, Micro SD , CAN , 28 I/Os (16DI+12DO) Program capacity: 64K steps

Size: 88 mm x 88 mm x 95.5 mm

IP Rating: IP20

Input Type: Digital

Output Type: Digital

Interface Type: CAN, Ethernet, RS-485, USB

Mounting Style: DIN Rail Mount

Number of Inputs: 1024 Input

Number of Outputs: 1024 Output

Supply Voltage - Max: 24 VDC, 240 VAC

Supply Voltage - Min: 24 VDC, 100 VAC

Maximum Operating Temperature: + 60 C

Minimum Operating Temperature: - 20 C
