Channel configuration
Channel number: 8
Channel optional function: TC Thermal Resistance Thermistor
Channel technical indicators:
Channel type: Range/ Measuring range/ Resolution/ Accuracy (at 20 ± 5 °C for 1 year)/ Temperature coefficient
Thermocouple/ 100 mV/ -20 mV ~ 100 mV/ 0.1 uV/ ± (60 ppm + 20 ppm)/ 3 ppm
RTD: 100 Ω/ 0 Ω ~ 125 Ω/ 0.1 mΩ/± (30ppm + 5 ppm)/ 1 ppm
RTD: 400 Ω/ 0 Ω ~ 400 Ω/ 0.1 mΩ/ ± (30 ppm + 5 ppm)/ 1 ppm
Temperature technical indicators: Type/Mearsuring range:
Thermocouples
K: - 200℃ ~ 1372℃
J: - 210℃ ~ 1200℃
T: - 200℃ ~ 400℃
E: - 200℃ ~ 1000℃
N: - 270℃ ~ 1300℃
B: 250℃ ~ 1820℃
R: - 50℃ ~ 1768℃
S: - 50℃ ~ 1768℃
RTDs
PT25: -189℃ ~ 961℃
PT100: -200℃ ~ 950℃
General technical indicators
Power requirement: 12V DC 2A
Communication interface: RS232, Wireless
Enclosure: Aluminum alloy + ABS
Dimensions (mm): 230 × 140 × 100
Weight (kg): 2
Operating environment: 5 to 35 °C, 0 to 85% RH
Storage environment: 0 to 70 °C, 0 to 100% RH
