Communication: RS485MODBUS-RTU
Response Time: T90＜10s
Work Pressure: ≤1 Bar
Sample Flow Rate: 0.5m/s≥ flow rate ≥0.001m/s
Operating Temp: 0~50℃ (doesnot freeze)
Storage Temp: 0~60℃ (does not freeze)
Dimension: Diameter: 38mm, length: 270 mm (Body: D38mm, L 270mm, Head: D 27mm
L: 115mm)
Mounting Thread: Immersedor pipedinstallation(Requires mounting accessory support)
Lead interface: One-pieceor split M16 connector
Protection Grade:IP68
Power Supply: 9~24VDC
Power Consumption: 0.2W
Weight: 550g
Cable Standard: 5 meters (otherlength can be customized)
Measuring Object: ORP
Measuring Technology: Electro chemicapl latinum electrodes
Measuring Range:ORP: ±2000mV, TEMP:0~50℃
Resolution: 1mV/ 0.1℃
Accuracy:0.1% of the range or ±2mV, take the larger one; Temp:±0.5℃
Shell Material: POM+Titanium alloy (canused for sea water)
