Dakota MX2-DL Corrosion Thickness Gauge (+ Rectified, - Rectified, Full Waveform (RF))

Transducer Probe Type: Dual Element

Measurement Accuracy: 0.01mm (0.001”)

Memory: 4GB Internal Memory

Operating Temperature: -10 to 60ºC (14 to 140ºF)

Data Output: USB

Power Supply: 3 x AA batteries and via USB

Battery Life: Alkaline – 35 hrs, Nicad – 10 hrs and NI-MH – 35 hrs

Gauge Weight: 383g (13.5oz) - including batteries

Gauge Dimensions: 63.5 x 165 x 31.5mm (2.5 x 6.5 x 1.24”)

Packing List: Unit, Selectable Transducer, Couplant, Manual, Plastic Carrying Case, Certificate of Calibration and AA Batteries. PC Software and Data Transfer Cable included with data logging gauges.

.
