DaiHan DH.WVB01030 Water Bath Viscosity (+5℃ -100 ℃, ±0.1℃; 2kW)

- Temp. Range & Accuracy Room Temp.: +5℃ to 100 ℃, ±0.1℃

- Temp. Resolution: 0.1℃-Display, 0.1℃-Control

- Temp. Uniformity & Probe: ±0.2℃ , PT100

- Heating Power: 2 kW

- Pump: Magnetic Drive, Max. Flow 30 Lit./min

- Timer & Alarm: 99hr 59min (Delay & Continuous run), Error status & Timer-end

- Display: Digital LCD with Back-Light Function

- Controller: Digital Fuzzy Controller with Jog-Shuttle Switch (Turn+Push)

- Safety Circuit: Over-Temp./-Current protection, Sensor Error Detection

- Lid: Included 5 Holes Stainless-steel Lid for Viscometer Holder

- Drain Valve: Mounted

- Viewing Window Size(mm): 230×180

- Material: Stainless-steel (＃304)-Internal, Powder Coated steel-External,

- Dimension (w×d×h)

Effective Space (mm): 330×300×h260 mm

Internal (mm): 350×300×h300 mm

External (mm): 585×375×h420 mm

- Packing Size (mm) & Gross Weight (kg): 640×450×h500 mm, 24 kg

- Electric Reqts.: 230V, 50 / 60Hz
