DaiHan Ref600-L SMART Laboratory Refrigerator (600L, 0~10℃)

Capacity & Doors: 600Lit, 1-Door

Temp. Range: 0~10.0 ℃(PT100 Sensor)at R/T of 30℃ and Humidity of 70%

Temp. Resolution: 1 ℃ -Display, 1 ℃-Control

Refrigerant: CFC-Free(R-404A) Refrigeration System

Compressor & Evaporator: 1/2 HP, Auto Exchange Dual Evaporator

Air Circulation: 4 EC FAN Forced-air type

Defrost: Automatic Defrost System

Controller & Display: Smart-Lab Controller, 7" Full Touch Screen TFT LCD, VIARen™ App Service

Door: Outer Door with Glass Window with Safety Door Lock System

Shelf (Included): 5 Teflon coated Steel Wire Shelf

Others: with Door Lock Device, Sensor Error Detection

Material:

+ Internal : Stainless-steel,

+ External : Powder Coated-steel

Dimension (w x d x h)

+ Infernal(mm): 620 x 770 x 1,290

+ Extemal(mm): 750 x 980 x 1,950

Net Weight: 150 kg

Power Consumption: 700 W

Electrical Reqts. : 1 Phase, AC 230V, 50/60Hz

Spare Teflon-coated Steel Wire Shelf

DH.RefSW0600 (a) Wire Shelf, Teflon-coated Steel, w600 x d660 mm, for "Ref600-P", "Ref600-L"

DH.RefSW1300 (a) Wire Shelf, Teflon-coated Steel, w660 x d660 mm, for "Ref1300-P", "Ref1300-L"
