Cybertek PA3026 Broadband Power Amplifier (DC-500kHz/ 130VA)

Power Bandwidth: DC-500kHz

Output specifications

Maximum output voltage:

300Vpp/±150V

RL=100Ω; 100Vrms(40Hz-200kHz); 40Vrms(20Hz-500kHz)

RL=300Ω; ±150V(DC-50kHz); ±140V(DC-200kHz); ±55V(DC-500kHz)

Maximum output current: 1.25Arms/3.5App (40Hz-500kHz); ±0.625A (DC-40Hz)

Slew rate: 450V/μs

Output impedance: ≪1Ω+3.2µH

DC offset: ±150V

Voltage current monitor: Voltage and current double channels output monitoring; Voltage attenuation coefficient 1/100; Current attenuation coefficient 1A/0.1V

Voltage current meter: Voltage current meter; RMS value indication

Input form: A/B two channels (Can be added), A/B for the output is in phase

Input impedance: 50Ω/10 kΩ optional

Input voltage: ±10V Maximum

Gain: 20/40/100/200 optional

Maximum output power (sine wave): 130VA

Maximum output power (square wave): 262.5W

Power supply: 220V±10%, 50/60Hz

Maximum power consumption: 300W

Dimensions: 420(W)x360(L)x210(H) mm

Weight: 9kg
