Bandwidth(-3dB): 200MHz
Rise time: ≤1.75ns
Accuracy: ±1%
Attenuation ratio: 10:1
(DC + Peak AC) Maximum differential voltagE: ±20V
Common mode voltage: ±60V
Maximum rated input voltage (to earth): ±60V
Input impedance
Single to earth: 500kΩ
Double input: 1MΩ
Input capacitance
Single to earth: ＜7pF
Double input: ＜3.5pF
Output voltage fluctuation: ±2V(50Ω Oscilloscope Input)
Offset (Typical value): ±2mV
Offset adjust range (Typical value): ±95mV
CMRR
50Hz/60Hz: ＞80dB
10MHz: ＞50dB
Noise(Vrms): 6mV
Overload indicator voltage threshold: ≥20V
Delay time
Probe main: 11ns
BNC(1m): 5ns
Overload indicator: Indicator will be lighted red when overload occurs
Terminal load requirement: 50Ω
Power supply: USB 5V/1A Adaptor
