Sensata Technologies - Crydom D2W202F Heavy Duty PCB SIP SSR 280VAC 2A, 3-32VDC,ZC

Width: 11.9 mm (0.469 in)

Height: 29.9 mm (1.177 in)

Length: 43.2 mm (1.701 in)

Output Type: Triac

Unit Weight: 17 g

Contact Form: SPST (1 Form A)

REACH - SVHC: Details

Input Current: 3 mA

Mounting Style: PCB Mount

Termination Style: Solder Pin

Relay Contact Form: 1 Form A (SPST-NO)

Load Current Rating: 2 A

Load Voltage Rating: 280 VAC

Control Voltage Range: 3 VDC to 32 VDC

Pd - Power Dissipation: 500 mW

Maximum Operating Temperature: + 80 C

Minimum Operating Temperature: - 30 C
