Sensata Technologies - Crydom D06D100K Controller 100A 60VDC; Input 3.5 32VDC; w Stndoff

Width: 44.5 mm

Height: 26.4 mm

Length: 57.3 mm

IP Rating: IP00

Output Type: MOSFET

Unit Weight: 86.500 g

REACH - SVHC: Details

Input Current: 10 mA to 15 mA

Mounting Style: Panel Mount

Relay Contact Form: 1 Form A (SPST-NO)

Load Current Rating: 100 A

Load Voltage Rating: 1 VDC to 60 VDC

Control Voltage Range: 3.5 VDC to 32 VDC

Maximum Operating Temperature: + 100 C

Minimum Operating Temperature: - 40 C
