Cosel PCA1000F-24-G Switching Supplies AC/DC PS (Enclosed Type) 1000W, 24V, 44A low leakage current

Width: 102 mm

Height: 41 mm

Length: 178 mm

Industry: Medical

Approvals: ANSI/AAMI ES60601-1, cUL (CSA60950-1), EN60601-1 3rd, EN60950-1, UL60950-1

Compliance: ANSI/AAMI ES60601-1, C-UL (CSA60950-1), EN60601-1 3rd, EN60950-1, UL60950-1

Efficiency: 91 %

Unit Weight: 1.2 kg

Output Power: 1.056 kW

Input Voltage: 85 VAC to 264 VAC

Mounting Style: Chassis

Input Frequency: 45 Hz to 66 Hz

Load Regulation: Regulated

Isolation Voltage: 4 kVAC

Number of Outputs: 1 Output

Open Frame/Enclosed: Enclosed

Output Current-Channel 1: 44 A

Output Voltage-Channel 1: 24 VDC

Maximum Operating Temperature: + 70 C

Minimum Operating Temperature: - 20 C
