Cosel CHS3002428-BC Isolated 252W 18-36Vin 28V 9A Baseplate Case

Width: 26.1 mm (1.028 in)

Height: 14.3 mm (0.563 in)

Length: 61.1 mm (2.406 in)

Dimensions: 61.1 mm x 26.1 mm x 14.3 mm

Unit Weight: 57 g

Output Power: 252 W

Input Voltage: 18 V to 36 V

Mounting Style: Through Hole

Isolation Voltage: 2.25 kV

Number of Outputs: 1 Output

Input Voltage - Max: 36 V

Input Voltage - Min: 18 V

Input Voltage, Nominal: 24 V

Output Current-Channel 1: 9 A

Output Voltage-Channel 1: 28 V

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C
