Cosel CBS1004824-RF1 Isolated 100W 24V 4.2A TH - HALF BRICK

Width: 57.9 mm (2.28 in)

Height: 12.7 mm (0.5 in)

Length: 61 mm (2.402 in)

Industry: Industrial

Efficiency: 88 %

Unit Weight: 83 g

Output Power: 100.8 W

Input Voltage: 36 V to 76 V

Cooling Method: Conduction

Mounting Style: Through Hole

Mechanical Style: Isolated

Isolation Voltage: 1.5 kV

Number of Outputs: 1 Output

Input Voltage - Max: 76 V

Input Voltage - Min: 36 V

Input Voltage, Nominal: 48 V

Output Current-Channel 1: 4.2 A

Output Voltage-Channel 1: 24 V

Maximum Operating Temperature: + 100 C

Minimum Operating Temperature: - 40 C
