Speed range: 0.2 ~ 330mm/min (adjustable)
Max. Capacity: 500 kN
Units: Force: gf, kgf, lbf, N, kN, ozf, tonf(SI), ton(long), tonf(short); Pressure: Kpa, Mpa, psi, bar, mm-Aq, mm-Hg
Force Resolution: 31 bits
Force Precision: 1/100,000
Test stroke(w/o grip): 1500 mm
Stroke resolution: 0.0001 mm
Space between columns: 550 mm(680mm, 800mm Optional)
PC-Port: RJ45(TCP/IP)(software optional)
Data sampling rate:Max.400Hz
Hardware safety protection: upper limit, lower limit, emergency stop button
Motor type: Servo Motor
Power Supply:3 phase 200~240 VAC，70 A
Dimension of Machine: 145 x 85 x 295cm
Weight of Machine:2350kg
