Coilcraft RFS1317-474KL Wirewound 470uH Shld 10% 1.1A 409mOhms
ManufacturerCoilcraft(View more products from this manufacturer)
ModelRFS1317-474KL
Contact
Secure Checkout
Quality Engagement
Easy change and return
Delivery Available
Length: 16 mm
Diameter: 13.3 mm
Shielding: Shielded
Tolerance: 10 %
Inductance: 470 uH
Application: Choke
Termination: Standard
Unit Weight: 9.400 g
Lead Spacing: 5 mm
Core Material: Ferrite
Lead Diameter: 0.8 mm
Mounting Style: PCB Mount
Test Frequency: 100 kHz
Termination Style: Radial
Maximum DC Current: 1.6 A
Saturation Current: 1.6 A
Maximum DC Resistance: 409 mOhms
Self Resonant Frequency: 1.2 MHz
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
