Coilcraft POE120PL-24L PoE Transformers 120W POE Planar 24V 5A 50uH
ManufacturerCoilcraft(View more products from this manufacturer)
ModelPOE120PL-24L
Contact
Secure Checkout
Quality Engagement
Easy change and return
Delivery Available
Width: 20.83 mm
Height: 9.64 mm
Length: 23.37 mm
Shielding: Unshielded
Inductance: 50 uH
Application: Active Clamp Forward Topology
Unit Weight: 12 g
Power Rating: 120 W
Core Material: Ferrite Core
Current Rating: 5 A
Frequency Range: 200 kHz
Isolation Voltage: 1.5 kV
Termination Style: SMD/SMT
Number of Channels: Single
Primary Resistance: 18.9 mOhms
Secondary Resistance: 13.6 mOhms
Maximum DC Resistance: 58.5 mOhms, 13.6 mOhms, 18.9 mOhms
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
