Coilcraft MSS1260-823MLD Power Inductor 82uH Shld 20% 2.2A 129mOhms AECQ2
ManufacturerCoilcraft(View more products from this manufacturer)
ModelMSS1260-823MLD
Contact
Secure Checkout
Quality Engagement
Easy change and return
Delivery Available
Width: 12.3 mm
Height: 6 mm
Length: 12.3 mm
Core Type: Drum
Shielding: Shielded
Tolerance: 20 %
Inductance: 82 uH
Application: Automotive
Termination: Standard
Unit Weight: 3 g
Core Material: Ferrite
Qualification: AEC-Q200
Mounting Style: PCB Mount
Test Frequency: 100 kHz
Termination Style: SMD/SMT
Maximum DC Current: 2.2 A
Saturation Current: 2.64 A
Maximum DC Resistance: 129 mOhms
Self Resonant Frequency: 8.6 MHz
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
