Coilcraft MLC1565-922MLC Power Inductor 9.2uH Shld 20% 10.18A 10.6mOhm AECQ
ManufacturerCoilcraft(View more products from this manufacturer)
ModelMLC1565-922MLC
Contact
Secure Checkout
Quality Engagement
Easy change and return
Delivery Available
Width: 13.2 mm
Height: 6.5 mm
Length: 14 mm
Core Type: Molded
Shielding: Shielded
Tolerance: 20 %
Inductance: 9.2 uH
Application: Power
Termination: Standard
Core Material: Iron Powder
Qualification: AEC-Q200
Mounting Style: PCB Mount
Test Frequency: 100 kHz
Termination Style: SMD/SMT
Maximum DC Current: 10.18 A
Saturation Current: 7.8 A
Maximum DC Resistance: 10.6 mOhms
Self Resonant Frequency: 25 MHz
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
