Coilcraft KA4823-CL Flyback KA4823 Flyback 220 Vac 10.5A
ManufacturerCoilcraft(View more products from this manufacturer)
ModelKA4823-CL
Contact
Secure Checkout
Quality Engagement
Easy change and return
Delivery Available
Width: 47.72 mm
Height: 30.48 mm
Length: 45.72 mm
Shielding: Unshielded
Inductance: 28 uH
Application: Solar Microinverter
Unit Weight: 94.300 g
Frequency Range: 150 kHz
Isolation Voltage: 3 kV
Termination Style: Through Hole
Maximum DC Current: 10.5 A
Number of Channels: Single
Primary Resistance: 8 mOhms
Secondary Resistance: 472 mOhms
Maximum DC Resistance: 472 mOhms, 8 mOhms
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
