Coilcraft HA4035-ALC Wirewound 330 nH Unshld 2% 850mA 135mOhms
ManufacturerCoilcraft(View more products from this manufacturer)
ModelHA4035-ALC
Contact
Secure Checkout
Quality Engagement
Easy change and return
Delivery Available
Width: 3.81 mm
Height: 3.43 mm
Length: 4.95 mm
Q Minimum: 80
Shielding: Unshielded
Tolerance: 2 %
Inductance: 330 nH
Application: RF
Termination: Standard
Unit Weight: 128 mg
Core Material: Ceramic
Mounting Style: PCB Mount
Test Frequency: 50 MHz
Termination Style: SMD/SMT
Maximum DC Current: 850 mA
Maximum DC Resistance: 135 mOhms
Self Resonant Frequency: 600 MHz
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
