Coilcraft DS1608B-104MLC Backlight Inductor 100uH Unshld 20% 220mA 950mOhms
ManufacturerCoilcraft(View more products from this manufacturer)
ModelDS1608B-104MLC
Contact
Secure Checkout
Quality Engagement
Easy change and return
Delivery Available
Width: 4.45 mm
Height: 2.92 mm
Length: 6.6 mm
Core Type: Drum
Shielding: Unshielded
Tolerance: 20 %
Inductance: 100 uH
Application: Power
Termination: Standard
Unit Weight: 160 mg
Core Material: Ferrite
Mounting Style: PCB Mount
Test Frequency: 100 kHz
Termination Style: SMD/SMT
Maximum DC Current: 220 mA
Maximum DC Resistance: 950 mOhms
Self Resonant Frequency: 12 MHz
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
