Cincon EC3AB25S Isolated DC-DC Converter, 3 Watt, 2:1 Input Range, 500VDC min. Isolation, Non-Conductive Black Plastic, 18-36VDC Input, +/-12VDC Output, SMD

Width: 20.3 mm

Height: 12.7 mm

Length: 31.8 mm

Dimensions: 31.8 mm x 20.3 mm x 12.7 mm

Efficiency: 80 %

Unit Weight: 15 g

Output Power: 3 W

Input Voltage: 18 V to 36 V

Cooling Method: Convection

Mounting Style: SMD/SMT

Mechanical Style: Isolated

Isolation Voltage: 500 V

Number of Outputs: 2 Output

Input Voltage - Max: 36 V

Input Voltage - Min: 18 V

Input Voltage, Nominal: 24 V

Output Current-Channel 1: 125 mA

Output Current-Channel 2: 125 mA

Output Voltage-Channel 1: 12 V

Output Voltage-Channel 2: - 12 V

Maximum Operating Temperature: + 71 C

Minimum Operating Temperature: - 25 C
