Cincon EC2A11 Isolated DC-DC Converter, 1.5 Watt, 12VDC Input, 5VDC Output, 500VDC min. Isolation, Non-Conductive Black Plastic, DIP-24

Width: 20.3 mm (0.799 in)

Height: 10.2 mm (0.402 in)

Length: 31.8 mm (1.252 in)

Efficiency: 50 %

Unit Weight: 12 g

Output Power: 1.5 W

Input Voltage: 10.8 V to 13.2 V

Cooling Method: Convection

Mounting Style: Through Hole

Mechanical Style: Isolated

Isolation Voltage: 500 V

Number of Outputs: 1 Output

Input Voltage - Max: 13.2 V

Input Voltage - Min: 10.8 V

Input Voltage, Nominal: 12 V

Output Current-Channel 1: 300 mA

Output Voltage-Channel 1: 5 V

Maximum Operating Temperature: + 71 C

Minimum Operating Temperature: - 25 C
