Chauvin Arnoux MA400D-1000 Clamp Meter (400A AC, 10 Hz ~ 3 kHz, TRMS)

Display range/Measurement range/Resolution/Accuracy

4A AC/ 0.020 A ~ 3.999 A/ 1 mA/ ±(2% + 10 cts)

40A AC/ 4.00 A ~ 39.99 A/ 10 mA/ ±(1.5%+ 2 cts)

400A AC/ 40.0 A ~ 399.9 A/ 100 mA/ ±(1.5%+ 2 cts)

Sensor clamping diam./ length: Ø 320 mm / 1,000 mm

Bandwidth: 10 Hz ~ 3 kHz

Power supply: 2 x 1.5 V AAA/LR3 batteries

Safety: IEC 61010 CAT IV 600V

Operating temperature: 0°C to +50°C

Instrument weight: Approx. 130 g

Casing dimensions: 100 x 60 x 20 mm

Connection cable length: 0.8 m

Accessories: 1 DigiFlex sensor, 2 x 1.5V AAA batteries, 1 elastic strap, 1 shoulder bag compatible with MultiFix and an operating manual in 5 languages

Accessories & Replacement Parts:

Bag 120 x 200 x 60: P01298074

MULTIFIX accessories: P01102100Z

Elastic strap: P01102113

Datasheet
