Ceyear 4052B Signal and Spectrum Analyzer (DC: 2Hz ~ 8GHz, AC: 10MHz ~ 8GHz)

Frequency Range:

DC: 2Hz ~ 8GHz

AC: 10MHz ~ 8GHz

10MHz Precise Frequency Reference

• Frequency accuracy: ± (last calibration date × aging rate + temperature stability + calibration accuracy)

• Aging rate: ± 5×10^-10/year

• Temperature stability: ± 5×10^-8

• Calibration accuracy: ± 4×10^-8

Span

• Range: 0Hz (zero span), 10Hz – the highest frequency of the model

• Accuracy: ± (0.1%× span＋span/ (sweep points number-1)

Sweep Time Range

• Span≥10Hz: 1ms – 16000s

• Span=0Hz: 1us – 16000s

RBW: 0.1Hz-20MHz (1, 2 ,3 ,5, steps)

VBW: 1Hz-20MHz (1, 2 ,3 ,5, steps)

Signal Analysis Bandwidth

• 10 MHz (Standard)

• 40 MHz (Optional)

• 200 MHz (Optional)

• 600 MHz (Optional)

• 1.2 GHz (Optional)

SSB Phase Noise (Carrier 1GHz, 20℃ -30℃)

• -95 dBc/Hz @ 100Hz offset

• -112 dBc/Hz @ 1kHz offset

• -122 dBc/Hz @ 10kHz offset

• -122 dBc/Hz @ 10kHz offset

• -135 dBc/Hz @ 1MHz offset

Trigger Source: Free, Line, Video, External level (front panel), External level (back panel), Burst RF, Timer

Trigger Detector: Normal, positive peak, negative peak, sample, video average, power average, voltage average

1dB Gain Compression

• 10MHz – 100MHz: 0dBm

• 100MHz – 1GHz: 0dBm

• 1GHz – 8GHz: +5dBm

• 8GHz – 50GHz: +5dBm

Residual Response: 200kHz – 8GHz: -90dBm

Power Supply: AC 100 – 240V: 50 – 60Hz

Dimension: Excluding the handle, brackets: （426±4）mm ×（177±4）mm ×（450±4）mm

Weight: About 25kg (different configuration cause different weight)

See more detail information in the Datasheet
