CEM DT-869IR IR Thermometer with UV Leak Detector (-20°C~600°C)

Imaging and optical data

Thermal sensitivity (NETD): 0.10°C (0.18°F) @ 1Hz and 100°C

Detector data

Detector type: Uncooled hyper-thin pyroelectric ceramic

Spectral range: 8±14μm

IR temperature Measurement

Object temperature range: –20°C to +600°C (–4°F to +1112°F)

Accuracy: ±3°C (±5.4°F) or ±2% of reading

Spotmeter: Center spot

Emissivity adjustable: 0.10~1.0 Adjustable

Field of View: 39° x 39°

Color palettes: GREY/GREY IRON/ IRON/RAINBOW

Image storage format: Standard BMP, including measurement data, on drivce > 100 pictures

Size (HxWxD): 195mm x 99mm x 51mm

Weight: 252g

UV Leak Detector with 5 UV/Blue LEDs (460-470nm)

Coaxial laser displays a circular set representation of the target area

Accessories:

2x1.5V“AA”batteries,Type K Temp. probe, USB cable, Carrying case and Gift box
