Function: Max Resolution ; Accuracy
Loop Impedance: 20/200/2000Ω ; ±2.5% rdg ±4dgts
AC Test Current: 20Ω 25A; 200Ω 2.3A;2000Ω 15mA ; ±2%rdg ±5dgts
AC Test Period: 20Ω 20ms; 200Ω 40ms;2000Ω 280ms ; ±2%rdg ±5dgts
PSC: 200A (2.3A 40ms); 2000A(25A 20ms); 20KA (25A 20ms) ; Consider accuracy impedance
Voltage: 50V ~ 250V ; ±2%rdg ±5dgts
Resistance: 0.1kΩ ; ±1.0%rdg ±2dgts
Operating Voltage: 230V + 10% - 15% (195V ~ 253V) 50Hz
Safety Standard: IEC61010-1 CATIII 600V
Size (H x W x D): 200mm x 92mm x 50mm
Weight: 582g
Accessories:
Test leads and “AA” Battery x 6, gift box with carrying case.
