Function: Max Range - Basic Accuracy
Voltage DC: 600V ; ±(0.5%+1d)
Voltage AC: 600V ; ±(1.5%+2d)
Current AC: 400A ; ±(2.5%+4d)
Resistance: 40MΩ ; ±(3.0%+5d)
Frequency: 10MHz ; ±(1.2%+2d)
Continuity check: Buzzer sounds at 30Ω
Diode test: Test current 0.3mA
Size (H x W x D): 230mm x 76mm x 40mm
Weight: 315g
Accessories: Test leads, gift box with carrying case, Temperature probe and 9V battery. USB cable and Software (356W)
Datasheet
Features | ||||||||
371 | 371B | 371BL | 372 | 373 | 375 | 375BT | 376 | |
Current measurement | AC | AC | AC | AC | AC/DC | AC/DC | AC/DC | AC/DC |
Max. Resolution | 1mA | 1mA | 1mA | 1mA | 10mA | 10mA | 10mA | 10mA |
LCD display counts | 2000 | 2000 | 2000 | 4000 | 4000 | 4000 | 6000 | 6000 |
AC True RMS | * | * | * | * | ||||
Display with backlight | * | * | * | * | * | * | * | * |
Data Hold | * | * | * | * | * | * | * | * |
Max Hold | * | * | * | |||||
Zero Function | * | * | * | * | ||||
Auto Power Off | * | * | * | * | * | * | * | * |
Low battery indication | * | * | * | * | * | * | * | * |
Bluetooth | * | |||||||
Peak Current | * | |||||||
Inrush Current | * | |||||||
1.2” (30mm) Jaw opening | * | * | * | * | * | * | * | * |
Specifications | ||||||||||
Function | Max Range | Basic Accuracy | 371 | 371B | 371BL | 372 | 373 | 375 | 375BT | 376 |
Voltage DC | 600V | ±(0.5%+1d) | * | * | * | * | * | * | * | * |
Voltage AC | 600V | ±(1.5%+2d) | * | * | * | * | * | * | * | * |
Current DC | 400A | ±(2.0%+5d) | * | * | * | 600A | ||||
Current AC | 400A | ±(2.5%+4d) | * | * | * | * | * | * | * | 600A |
Flexible A | 3000A | ±(3.0%+5d) | * | |||||||
Resistance | 40MΩ | ±(3.0%+5d) | 20MΩ | 20MΩ | 20MΩ | * | * | * | 60MΩ | 60MΩ |
Temperature | 1000ºC/1832ºF | ±(3.0%+3d) | * | * | * | * | ||||
Capacitance | 100uF | ±(2.5%+5d) | * | 4000μF | 6000μF | 6000μF | ||||
Frequency | 10MHz | ±(1.2%+2d) | * | * | * | * | * | |||
Inrush Current | 400A | ±(1.5%+2d) | * | |||||||
Continuity check | Buzzer sounds at 50Ω | * | * | * | 30Ω | 30Ω | * | * | * | |
Diode test | Test current 0.3mA | * | * | * | * | * | * | * | * | |
