CEM CAM979 Professional Thermal Imaging Camera (-20°C~400°C, 160x120)

Imaging and optical data

Field of view (FOV) / Minimum focus distance: 29.8°x 22.6°/ 0.2m

Spatial resolution (IFOV): 3.33mrad

Thermal sensitivity/NETD: < 0.08°C @ + 30°C(+86°F)/80mK

Image frequency: 50Hz

Focus mode: Manual

Focal length: 7.5mm

Focal Plane Array(FPA)/Spectral range: Uncooled microbolometer/8-14 µm

IR resolution: 160x120

Image presentation

Image modes: IR image, visual image

Color palettes: IRON, Rainbow, Grey, Grey Inverted, Sepia, Blue_Red, Hot_Cold, Humidity

Measurement

Object temperature range: –20°C ~ +150°C (–4°F ~ +302°F), 0°C to +400°C (+32°F to +752°F)

Accuracy: ±2°C (±3.6°F) or ±2% of reading

Data communication interfaces

Interfaces: composite video

Video out: Composite (PAL and NTSC)

Ethernet type, connector type, video streaming: 100Mbps, RJ-45,H.264

Alarm output: 2 relay output

Options Lens

11mm: 20.6°x 15.5°

22mm: 10.4°x 7.8°

33mm: 6.9°x 5.2°

Size (HxWxD): 90mm x 74mm x 74mm

Weight: 1000g

Accessories:

Infrared camera with lens, CVBS cable, RS485 cable, Network cable, Gift box.
