CEM CAM978 Professional Thermal Imaging Camera (-20°C~400°C, 384x288)

Imaging and optical data

Field of view (FOV) / Minimum focus distance: 24.6°x 18.6°/ 0.5m

Spatial resolution (IFOV): 1.14mrad

Thermal sensitivity/NETD: <0.05oC/50mK

Image frequency: 50Hz

Focus mode: Manual

Focal length: 22mm

Focal Plane Array(FPA)/Spectral range: Uncooled microbolometer/8-14 µm

IR resolution: 384x288

Image presentation

Image modes: IR image only

Color palettes: IRON, Rainbow, Grey, Grey Inverted, Sepia, Blue_Red, Hot_Cold, Humidity

Measurement

Object temperature range: –20°C to +150°C (–4°F to +302°F), 0°C to +400°C (+32°F to +752°F)

Accuracy: ±2°C (±3.6°F) or ±2% of reading

Data communication interfaces

Interfaces: USB, composite video

USB: Remote control

Video out: Composite (PAL and NTSC)

Ethernet type, connector type，video streaming

Alarm output: 2 relay output

Power system

Input voltage: DC 9V to 12V

Options Lens

11mm: 7.1°x 36.2°

38mm: 14.4°x 10.8°

Size (HxWxD): 130mm x 60mm x 74mm

Weight: 1000g

Accessories:

Infrared camera with lens, CVBS cable, RS485 cable, Network cable, Gift box.
