Carling Technologies LRGSCK611-C-G-B-A/250N Super Curvette Rocker Switch LRGSCK611CGBA/250N

Life: 100000 Cycle

Color: Black

Width: 29.08 mm

Height: 20.45 mm

Legend: OFF - ON (Vertical)

Length: 31.5 mm

Actuator: Clear Rocker

Material: Nylon

Lamp Type: Neon

Illuminated: Illuminated

Contact Form: DPST

Panel Cutout: 28.58 mm x 25.4 mm

Mounting Type: Snap In

Terminal Seal: Sealed

Actuator Style: Clear Rocker

Current Rating: 15 A, 20 A

Mounting Style: Panel Mount

Panel Thickness: 4.74 mm

Switch Function: OFF - NONE - ON

Housing Material: Nylon

Actuator Material: Polycarbonate (PC)

Termination Style: Quick Connect

Voltage Rating AC: 125 VAC, 250 VAC

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C
