Carling Technologies CTB-B-B-10 Thermal 1-pole, Rocker, 125-250 VAC/ 50 VDC 10 amp circuit breaker, 1000 amp interrupting capacity 0.250 Tab (Q.C.) terminals Black Bezel Front Panel Snap-In UL 1077 Recognized cUL VDE Certified to IEC/EN 60934

Width: 13.71 mm

Length: 38.99 mm

Compliance: UL; cUL; VDE; CE

Illuminated: Non-Illuminated

Unit Weight: 15.583 g

Actuator Type: Rocker

Current Rating: 10 A

Mounting Style: Panel Mount

Voltage Rating: 250 VAC, 32 VDC

Number of Poles: 1 Pole

Termination Style: Quick Connect

Voltage Rating AC: 125 VAC to 250 VAC

Voltage Rating DC: 50 VDC

Maximum Operating Temperature: + 60 C

Minimum Operating Temperature: - 10 C
