Carling Technologies 61112283-E-0-N Small-Sized Rocker Switches 61112283E0N

Life: 50000 Cycle

Color: Black

Width: 14.98 mm

Height: 17.2 mm

Legend: No Legend

Length: 20.95 mm

Actuator: Paddle

Material: Nylon

Illuminated: Non-Illuminated

Contact Form: DP

Panel Cutout: 19.81 mm x 12.9 mm

Mounting Type: Snap In

Terminal Seal: Epoxy

Actuator Style: Paddle

Current Rating: 2 A, 5 A

Mounting Style: Panel Mount

Actuator Length: 11.81 mm

Panel Thickness: 2.36 mm to 3.96 mm

Switch Function: (ON) - OFF - (ON)

Housing Material: Nylon

Actuator Material: Nylon

Termination Style: Wire Lead

Voltage Rating AC: 125 VAC, 250 VAC

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: 0 C
