California Instruments 2003RP California Instruments Ac Power Source (675Va/Phase)

Output

Phases: 3 (A,B,C)

Phase Angles: A=0°, B=240°, C=120°

AC Power: 675VA Max per phase

Load Connection Floating neutral (option): Rear panel terminal block

RP Series : Product Specifications

Output : Voltage

High range / Low Range: 0-270/0-135 V RMS (except -AV)

Accuracy: ± 0.1 %FS @ 16Hz-100 Hz

Accuracy: ± 0.2%FS @ 100Hz-5000Hz

Resolution: 0.1 V

Load Regulation remote sense: 16-500Hz, ± 0.1% FS

Line Regulation 10 % Line change: ± 0.02%FS

T.H.D: 16-100Hz 0.5 typ./1.0 max.%; 100-2000Hz 1.0 typ./2.0 max.%

Output Noise: < 0.1 V RMS typ.

Output : Frequency (specifications valid from 45 Hz to 500 Hz)

Range: 16 - 5000Hz

Accuracy: ± 0.02%

Resolution

16.0Hz-80.0Hz 0.01 Hz

80.1Hz-800.0Hz 0.1 Hz

800Hz-5000Hz 1Hz

Output : Current

Steady State Current High V range: 2.5 A rms / ø

Steady State Current Low V range: 5.0 A rms / ø

Peak Current High V range: 7.5 A peak / ø

Peak Current Low V range: 15.0 A peak / ø

Input

Line Voltage 2 wire + GND: 107/115V or 208/230V ± 10% V RMS (set by jumper)

Line Current (fused): <30@115V,<15@230V A RMS

Line Frequency: 47 - 440 Hz

Holdup Time: 10 ms

Power Factor: 0.7

Isolation Input/output to Chassis: 1350 V / 2200 V
