C&W CW1602 Humidity Conditioning Cabinet (200L)

External dimensions (LxWxH): 1030 x 700 x 1035 mm

Internal dimensions (LxWxH1xH2): 610 x 510 x 455 x 660 mm

Panel capacity: 80

Power supply Amp: 16

Style: Floor Mounted

Condenser Unit:

- Floor Mounted Unit to stand next to test cabinet connected by two flexible hoses

- Condenser dimensions: 700 x 1150 x 540 mm (LxWxH)

Power supply: 230V, 50/60Hz Single-phase, other voltage on request.

Water type: De-ionized or mains water below 50 mg/litre TDS

Water pressure: 2 - 4 bar (30 to 60 psi)

Drain: 36 mm outside diameter plastic pipe liquid waste

Scope of supply:

Each Humidity Conditioning Cabinet comes with:

1x CW4088 Installation kit

1x CW4035 Set of Collection Vessel (2 funnel, 2 cylinder)

1x CW5882 Adapter for pipe

1x VF7101 Corrosion Handbook
