Brooks Instrument CMCA Capacitance Manometers (10 Torr, ±0.25%)

Electrical Connector: 15-pin sub D, 0-10 Vdc on 6" cable

Fitting: KF16

Full scale range: 10 Torr

Performance

Accuracy: 0.25%

Resolution: Infinite, limited by output noise (≤0.0006% F.S.)

Temp. Effect on Zero: 0.005% F.S. / °C

Temp. Effect on Span: 0.027% F.S. / °C

Response Time: 20 msec

Operating Temperature: 0 to 80°C

Compensated Temperature: 0 to 50°C

Mechanical

Exposed Materials: Inconel®

Over-Pressure Limit: 45 psia

Weight: 0.3 lbs. (137 grams)

Electrical

Input Power: +12 to 30 Vdc

Output Signal: 0-10 Vdc (<10K Ω load)

Power Consumption: <200 mW

Certifications

Electromagnetic Compatibility: Fully CE certified to EMC Directive 89/336/EEC

For more details, see datasheet.
