Broadcom HFBR-5963ALZ Transceivers OC3/FE 2X5 LC SD LVT TL EX TP ROHS

Width: 13.59 mm

Height: 11.3 mm

Length: 48.19 mm

Function: Transceivers for ATM, FDDI, Fast Ethernet and SONET OC-3/SDH STM-1 with LC connector.

Data Rate: 125 MBd, 155 MBd

Fall Time: 3 ns, 2.2 ns

Rise Time: 3 ns

Fiber Type: Multimode

Wavelength: 1300 nm

Application: Ethernet

Unit Weight: 18.643 g

Connector Type: LC

Emitting Source: LED

Maximum Output Current: 50 mA

Operating Supply Voltage: 3.3 V

Form Factor, or Case Style: SFP

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C
