Broadcom ASMT-AB31-NMP00 Mid-Power LEDs Blue, 470nm 30lm, 700mA
ManufacturerBroadcom(View more products from this manufacturer)
ModelASMT-AB31-NMP00
Contact
Secure Checkout
Quality Engagement
Easy change and return
Delivery Available
Width: 7.4 mm
Height: 4.1 mm
Length: 7.4 mm
LED Size: 7.4 mm x 4.1 mm
Lens Color: Colorless
Lens Shape: Dome
Unit Weight: 500 mg
Power Rating: 3 W
Viewing Angle: 140 deg
Mounting Style: SMD/SMT
Lens Dimensions: 6 mm
Lens Transparency: Clear
Illumination Color: Blue
Moisture Sensitive: Yes
If - Forward Current: 350 mA
Vf - Forward Voltage: 3.2 V
Luminous Flux/Radiant Flux: 30 lm
Wavelength/Color Temperature: 460 nm
Maximum Operating Temperature: + 120 C
Minimum Operating Temperature: - 40 C
