Broadcom ASMB-LTD2-0A333 Multi-Color LEDs 2121 PLCC4 tricolor

Width: 2.1 mm

Height: 1 mm

Length: 2.1 mm

Lens Color: Colorless

Lens Shape: Square

Unit Weight: 715.250 mg

Power Rating: 62.5 mW, 51 mW, 51 mW

Viewing Angle: 110 deg

Mounting Style: SMD/SMT

Lens Dimensions: 2.1 mm x 2.1 mm

Lens Transparency: Diffused

Illumination Color: RGB

Luminous Intensity: 390 mcd, 870 mcd, 190 mcd

Moisture Sensitive: Yes

If - Forward Current: 15 mA, 10 mA, 10 mA

Vf - Forward Voltage: 2.1 V, 2.9 V, 2.9 V

Wavelength/Color Temperature: 621 nm, 522 nm, 468 nm

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C
