Broadcom AFBR-390525RZ Transceivers REGULUS FLEX SH LINK 5MBAUD, 1INCH

Width: 10.16 mm

Height: 7.7 mm

Length: 30.46 mm

Data Rate: 5 MBd

Fall Time: 10 ns

Rise Time: 10 ns

Wavelength: 650 nm

Application: Industrial

Unit Weight: 7.819 g

Connector Type: No Connector

Mounting Style: Through Hole

Emitting Source: LED

Moisture Sensitive: Yes

Description/Function: High voltage galvanic insulation link

If - Forward Current: 10 mA

Vr - Reverse Voltage: 3 V

Maximum Output Current: 30 mA

Pd - Power Dissipation: 330 mW

Operating Supply Voltage: 3.3 V, 5 V

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C
