Bourns SRR0745A-151M Power Inductor 150uH 20% SMD 0745 AEC-Q200
ManufacturerBourns(View more products from this manufacturer)
ModelSRR0745A-151M
Contact
Secure Checkout
Quality Engagement
Easy change and return
Delivery Available
Width: 7.3 mm
Height: 4.5 mm
Length: 7.3 mm
Core Type: Wirewound
Shielding: Shielded
Tolerance: 20 %
Inductance: 150 uH
Application: Automotive
Termination: Standard
Unit Weight: 1 g
Core Material: Ferrite
Qualification: AEC-Q200
Mounting Style: PCB Mount
Test Frequency: 1 kHz
Termination Style: SMD/SMT
Maximum DC Current: 480 mA
Saturation Current: 580 mA
Maximum DC Resistance: 760 mOhms
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
